ETA5406 AC flexible current probe

ETA5406 oscilloscope flexible current probe, the coil is light and soft, and can be freely inserted, can detect many hard probe can not reach the place, easy to connect with the measured object; It has almost zero interference to the measured object. The standard BNC output interface is very convenient to connect with oscilloscope, data collector, digital voltmeter, etc. to observe the current waveform and meet the test requirements of special occasions.

Main applications:

Measurement of harmonic components in current

Detecting sinusoidal current waveform

Measuring phase shift in sine wave

Current of semiconductor switch

Distributed current monitoring

Power bus monitoring

Monitoring harmonics, power and power quality

Test of large motor, pump and fan

Current measurement of IGBT and MOSFET


ModelETA5406
Specifications
Measuring range30A/300A/3000A AC
Output accuracy50mV/5mV/0.5mV per （AC coupled）
Error (45 ~ 65Hz)

±1% of reading ±0.1A 60A range

±1% of reading ±1A    600/6000A range


Minimum load100KΩ for specified accuracy
Frequency range10Hz...10KHz（-1dB）
Phase (45 ~ 65Hz)<±1。
Position sensitivity±2% of reading
Outfield±0.2% of reading with cable>200mm(8") from the probe
Noise

80mV rms in 60A range

400mv rms in 600A/6000A ranges


Temperature system±0.1% of reading/ ℃
Power SupplyTwo AA mn1500 LR6 alkaline batteries,or an external power supply (+3V/100mA)
Battery lifeTypical value of 2000 hours
External power supplyThrough 2.1 mm mini power connector (not provided)
Low powerOrange LED indication
overrangeRed LED indication
Enclosure
Material ScienceARNITE T06-200SNF,UL94 V0
Protection levelip40
Sensor length915mm
Output0.5m coax cable terminated with a safety bnc
Material ScienceAlcryn 2070NC,LATI LATENE 7H2W V0
Protection levelIP65
General characteristics
Operating temperature-20~65℃
Storage temperature-40~75℃
Operating humidity10%-85%RH
Safety standards

EN61010-1

EN61010-2-032


EMC
EN61326-2-2
