ETA4512 double clip test line, with alligator clip at both ends, stainless steel conductor for alligator clip, fully enclosed silicone sheath, test conductor using multi-strand tin-plated copper wire, enclosed with silicone rubber insulation layer, is widely used in teaching instruments, electrical and power testing instruments, automobile testing instruments, medical instruments and so on.
-The jagged jaw seams tightly and the thin thread can be easily clamped and not loosened.
-Alligator clip uses fully enclosed silicone sheath, which is frost-proof and high temperature resistant (sheath temperature-50℃to + 100℃)
-Silicone conductor is soft, high-pressure resistant, freeze-proof and high-temperature resistant (sheath temperature-resistant-50℃to+200℃)
-The conductor of multi-strand tin-plated copper wire has low resistance, good conductivity, bending resistance and oxidation resistance.
| Product name | Test lead |
| Model | ETA4512 |
| Safety grade | 1000V CAT Ⅲ |
| Current | 10A Max |
| Plug insulation type | Exposed type |
| Jack connection size | 4mm |
| Conductor cross-sectional area | 1mm2 |
| Insulator material | Silicon rubber |
| Length | 100CM |
| Color | Red, black, yellow, green, blue |
